產(chǎn)品規(guī)格 | 直徑(m) | 長度(m) | 斜度(%) | 產(chǎn)量(t/d) | 轉(zhuǎn)速(r/min) | 電機功率(kw) | 總重量(t) |
Φ2.5×40 | 2.5 | 40 | 3.5 | 180 | 0.44-2.44 | 55 | 149.61 |
Φ2.5×50 | 2.5 | 50 | 3.0 | 200 | 0.62-1.86 | 55 | 187.37 |
Φ2.5×54 | 2.5 | 54 | 3.5 | 280 | 0.48-1.45 | 55 | 196.29 |
Φ2.7×42 | 2.7 | 42 | 3.5 | 320 | 0.10-1.52 | 55 | 198.50 |
Φ2.8×44 | 2.8 | 44 | 3.5 | 450 | 0.437-2.18 | 55 | 201.58 |
Φ3.0×45 | 3.0 | 45 | 3.5 | 500 | 0.5-2.47 | 75 | 210.94 |
Φ3.0×48 | 3.0 | 48 | 3.5 | 700 | 0.6-3.48 | 100 | 237.00 |
Φ3.0×60 | 3.0 | 60 | 3.5 | 800 | 0.3-2 | 100 | 310.00 |
Φ3.2×50 | 3.5 | 50 | 4.0 | 1000 | 0.6-3 | 125 | 278.00 |
Φ3.3×52 | 3.3 | 52 | 3.5 | 1300 | 0.266-2.66 | 125 | 283.00 |
Φ3.5×54 | 3.5 | 54 | 3.5 | 1500 | 0.55-3.4 | 220 | 363.00 |
Φ3.6×70 | 3.6 | 70 | 3.5 | 1800 | 0.25-1.25 | 125 | 419.00 |
Φ4.0×56 | 4.0 | 56 | 4.0 | 2300 | 0.41-4.07 | 315 | 456.00 |
Φ4.0×60 | 4.0 | 60 | 3.5 | 2500 | 0.396-3.96 | 315 | 510.00 |
Φ4.2×60 | 4.2 | 60 | 4.0 | 2750 | 0.41-4.07 | 375 | 633.00 |
Φ4.3×60 | 4.3 | 60 | 3.5 | 3200 | 0.396-3.96 | 375 | 583.00 |
