型號 Model |
筒體轉速 Cylinder speed (r/min) |
裝球量 Balls load (t) |
進料粒度 Feeding size (mm) |
出料粒度 Discharge size (mm) |
生產(chǎn)能力 Capacity (t/h) |
電動機功率 Motor Power (kw) |
重量 Weight (t) |
Φ900×1800 |
36 |
1.5 |
≤20 |
0.075-0.89 |
0.65-2 |
18.5 |
4.6 |
Φ900×3000 |
36 |
2.7 |
≤20 |
0.075-0.89 |
1.1-3.5 |
22 |
5.6 |
Φ1200×2400 |
36 |
3 |
≤25 |
0.075-0.6 |
2.2-4.8 |
30 |
10.5 |
Φ1200×3000 |
36 |
3.5 |
≤25 |
0.074-0.4 |
2.7-5 |
37 |
11.8 |
Φ1200×4500 |
32.4 |
5 |
≤25 |
0.074-0.4 |
4-7.5 |
55 |
13.8 |
Φ1500×3000 |
29.7 |
7.5 |
≤25 |
0.074-0.4 |
4.3-8 |
75 |
15 |
Φ1500×3500 |
29.7 |
7.5 |
≤25 |
0.074-0.4 |
4.5-9 |
75 |
16.5 |
Φ1500×4500 |
27 |
11 |
≤25 |
0.074-0.4 |
6-12 |
90 |
18 |
Φ1500×5700 |
28 |
12 |
≤25 |
0.074-0.4 |
7-15 |
130 |
22 |
Φ1830×3000 |
25.4 |
11 |
≤25 |
0.074-0.4 |
6.5-12 |
130 |
28 |
Φ1830×3600 |
25.4 |
13 |
≤25 |
0.074-0.4 |
8-13 |
130 |
30 |
Φ1830×4500 |
25.4 |
15 |
≤25 |
0.074-0.4 |
10-18 |
155 |
32 |
Φ1830×6500 |
24.1 |
21 |
≤25 |
0.074-0.4 |
14-26 |
210 |
35 |
Φ1830×7000 |
25 |
23 |
≤25 |
0.074-0.4 |
15-28 |
245 |
37 |
Φ2100×3000 |
23.7 |
15 |
≤25 |
0.074-0.4 |
9-16 |
180 |
39 |
Φ2100×3600 |
23.7 |
18 |
≤25 |
0.074-0.4 |
10-19 |
210 |
41 |
Φ2100×4500 |
23.7 |
24 |
≤25 |
0.074-0.4 |
13-24 |
245 |
55 |
Φ2100×7000 |
23.7 |
26 |
≤25 |
0.074-0.4 |
20-37 |
280 |
50 |
Φ2200×4500 |
21.5 |
27 |
≤25 |
0.074-0.4 |
14-26 |
280 |
60 |
Φ2200×7000 |
21.7 |
35 |
≤25 |
0.074-0.4 |
22-41 |
380 |
63 |
Φ2400×3600 |
21 |
23 |
≤25 |
0.074-0.4 |
14-25 |
320 |
69 |
Φ2400×4500 |
21 |
27 |
≤25 |
0.074-0.4 |
17-32 |
380 |
80 |
Φ2400×7000 |
20.9 |
42 |
≤25 |
0.074-0.4 |
26-49 |
480 |
90 |
Φ2700×3600 |
20.7 |
33 |
≤25 |
0.074-0.4 |
19-32 |
380 |
94 |
Φ2700×4000 |
20.7 |
35 |
≤25 |
0.074-0.4 |
20-36 |
380 |
98 |
Φ2700×4500 |
20.7 |
38 |
≤25 |
0.074-0.4 |
21-40 |
480 |
116 |
Φ2700×7000 |
20.7 |
55 |
≤25 |
0.074-0.4 |
33-62 |
630 |
185 |
Φ3200×4500 |
19 |
56 |
≤25 |
0.074-0.4 |
35-68 |
800 |
132 |
Φ3200×7000 |
18 |
73 |
≤25 |
0.074-0.4 |
47-78 |
1250 |
185 |
Φ3600×4500 |
17 |
76 |
≤25 |
0.074-0.4 |
49-82 |
1250 |
185 |
Φ3600×6000 |
17 |
100 |
≤25 |
0.074-0.4 |
52-96 |
1400 |
235 |
Φ3600×8500 |
17 |
130 |
≤25 |
0.074-0.4 |
70-130 |
1800 |
270 |
Φ3800×6500 |
16.7 |
121 |
≤25 |
0.074-0.4 |
73-137 |
1800 |
277 |
Φ3800×8500 |
16.7 |
158 |
≤25 |
0.074-0.4 |
82-143 |
2000 |
305 |
Φ4000×6000 |
16.7 |
135 |
≤25 |
0.074-0.4 |
90-160 |
2000 |
315 |
