設備型號 Equipment Model |
YG935E69L |
YG935FW1214 II L |
YG1138E71L |
YG1138FW315 II L |
YG1138EW86L |
給料機型號Feeder model |
GZD-960x3500 |
GZD-960x3500 |
GZD-1100x3800 |
GZD-1100x3800 |
GZD-1100x3800 |
破碎機型號Crusher model |
PE600x900 |
PE-1214 II |
PE750x1060 |
PEW-1315 II |
PEW860 |
主皮帶型號Main belt model |
B800x8.5M |
B800x8.5M |
B1000x9M |
B1000x9M |
B1000x9M |
主皮帶卸料高度 Main belt discharge height |
3200 |
3200 |
3500 |
3500 |
3500 |
側出皮帶型號(選配)Side belt type(optional) |
B450x3M |
B450x3.2M |
B500x3.5M |
B500x3.5M |
B500x3.5M |
側皮帶卸料高度 Side belt dischage height |
2800 |
2800 |
3100 |
3000 |
3100 |
發動機功率Engine power(kw) |
180 |
250 |
200 |
300 |
250 |
運輸長度 Transport length(mm) |
11900 |
11900 |
13300 |
13300 |
14200 |
運輸寬度 Transport width(mm) |
3100 |
3100 |
3100 |
3100 |
3300 |
運輸高度 Transport height(mm) |
3650 |
3650 |
4500 |
4500 |
5000 |
運愉重量 Shipping weight(t) |
43.5 |
50 |
59 |
59 |
67 |
作業長度 Working length(mm) |
12100 |
12100 |
13500 |
13500 |
15200 |
作業寬度Job width(mm) |
3100 |
3100 |
3100 |
3100 |
3300 |
作業高度 Working height(mm) |
4100 |
4100 |
5100 |
4800 |
5500 |
